Combo Mid Strip 6 Tall

SKU: C-6T-MS
Price
$14
Taxes and shipping calculated at checkout
1. Include:: 3mm screws--24 per
Shop Pay
Visa
Mastercard
American Express
PayPal
Apple Pay
Meta Pay
Google Pay

Product information

Name: Combo P5 and P10 Matrix Maker Strips Mid Strip 6 Tall (Sold per strip)

Description:

The Combo Matrix Maker Strips are used to mount P5 or P10 panels into a full matrix.

Features:

The Combo Matrix Maker Strips continue the evolution of using P5 or P10 panel in a display. The Matrix Maker Strips simplify the process of figuring out what parts you need to make a matrix by only comprising of 2 parts compared to our P10 Matrix Maker Connectors. You only need to decide on how tall you want to make the matrix. The Matrix Maker Strips are designed for a matrix that is 2, 3, 4, 5, 6, 7, & 8 panels tall while being able to be infinitely long. You will need to order one set of P5 or P10 Matrix Maker End Strips (sold in pairs) and a P5 or P10 Matrix Maker Mid Strip for each joint of your matrix. Designed to work with our P5 or P10 Power Plate that mounts both the BBB and the power supply. Additional Mini Power plates can be added for multiple power supplies. The stand alone BBB mount does not work with the P5 or P10 Matrix Maker Strips. Each strip includes all screws required to mount to your panels and power supply.

**Made universal to fit Vendor panels, we work with Crockett Fantasy of Lights, Wired Watts, DIY LED Express** They could fit others but we can't guarantee since panels can vary.

  • Durable ABS construction
  • Relieves stress from the panels
  • Works with inexpensive 16x32 for P10 or 32x64 for P5
  • Super fast and easy installation
  • 100% American Made from Material, Design, and Fabrication

Assembly:

Once you figure out the shape and size of the matrix you want to build you will need to order the proper Matrix Maker Strips. Lay out the matrix panels by aligning the data arrows to all match and start applying the Matrix Maker connectors. Once you have it layed out adjust screws to get panels flush.
